Biograph Horizon
Jump to:
Bring high-quality care to more patients.
The Biograph™ Horizon from Siemens Healthineers gives you the flexibility to address a wide variety of clinical indications while introducing new efficiencies and cost savings. Designed with technologies that set the standard in PET/CT, the Biograph Horizon offers you premium performance at an attractive level of investment.
/PET-CT/Biograph%20Horizon/SH_MI_40388_15_rt_RGB_72ppi-4x3.jpeg)
Set the standard in PET/CT
The value of PET/CT is in the details. More precise information leads to greater potential for an earlier diagnosis and a more definitive treatment strategy, helping to improve patient outcomes. The entire product portfolio from Siemens Healthineers is built on technology that adds up to more. The wide range of features expands your clinical capabilities and delivers excellent lesion detectability, spatial resolution, and quantification accuracy, letting you deliver a high standard of care to more patients.
Reach more patients
Use all commercially available PET tracers to address a broader range of oncology, neurology, and cardiac indications. With premium LSO-based detectors and Time-of-Flight technology, you can go beyond the capabilities of BGO-based PET/CT scanners for high count-rate applications.
Do more with your time
Help your staff focus on what matters most: your patients. The Biograph Horizon offers protocol-based exams to support a more standardized workflow and is equipped with built-in capabilities that automate routine tasks.
Create more opportunity
Built to run as efficiently as possible, reduce operating costs and extend the economic life of your system, the Biograph Horizon supports your business. Offering the standard in PET/CT technology at an attractive total cost of ownership, your scanner has the flexibility to grow with you.
Technical Details
| Gantry | |
|---|---|
| Bore diameter | 78 cm |
| Tunnel length | 136 cm |
| Table capacity | 227 kg (500 lb) |
| CT | |
| Generator power | 80 kW (100 kW optional) |
| Rotation times | 0.33, 0.305, 0.285 s |
| Tube voltages | 70, 80, 100, 120, 140 kV |
| Iterative reconstruction | SAFIRE5 |
| Metal artifact reduction | iMAR5 |
| Slices | 64, 128 |
| PET | |
| Axial field of view | 26.3 cm |
| Crystal size | 3.2 x 3.2 x 20 mm |
| SiPM coverage of crystal array | 100% |
| Effective sensitivity | 100 cps/kBq |
| Effective peak NEC rate | 1,789 kcps ≤ 30 kBq |
| Time of flight performance | 214 ps |
