Precision-driven performance

Redefine PET/CT imaging with the precision-driven performance of Biograph Vision™1 from Siemens Healthineers. With industry-leading technical specifications, Biograph Vision delivers next-level image quality that transforms accurate decision-making.2,3


Redefined technical precision

Biograph Vision’s groundbreaking technological performance redefines the limits of imaging. Featuring 3.2-mm lutetium oxyorthosilicate (LSO) crystals that are 100% covered by SiPMs2, Biograph Vision’s Optiso Ultra Dynamic Range (UDR) detector technology delivers high 48-mm3 volumetric resolution2 and 214-ps "true" time-of-flight performance.3 Biograph Vision leverages the full potential of SiPM technology to reveal the bigger picture for accurate and confident decision-making.


Unlocking imaging versatility

Unlock more clinical and research capabilities with Biograph Vision’s state-of-the-art detectability. Biograph Vision provides high image resolution and sensitivity for precise quantification that can positively impact health outcomes. UDR provides outstanding performance for a wide spectrum of count rates, enabling a broad variety of radiotracers at optimal doses.


Empowered operational performance

Biograph Vision empowers users to reduce scan time and injected dose to boost productivity, avoid unnecessary exposure, and increase patient comfort with the market’s highest effective sensitivity3 at 100 cps/kBq. Enhance patient and user experience with intelligent imaging capabilities that drive greater throughput while providing more consistent and accurate results. No matter the user, the patient,5 or the procedure, Biograph Vision delivers exceptional outcomes.


3.2-mm LSO crystals

  • For improved, more precise imaging

SAFIRE (Optional)

  • CT iterative reconstruction to reduce dose and maintain image quality

FlowMotion AI ™ (Optional)

  • Personalize scans based on anatomy and standardize imaging protocols based on indication

Optiso UDR detector

  • 100% SiPM coverage of the LSO array

OncoFreeze™ / OncoFreeze AI (Optional)

  • Motion management without extending scan time and, if preferred, without the need for a gating device

Whole-body dynamic imaging (Optional)

  • Routine whole-body dynamic imaging enabled by FlowMotion™ continuous bed motion

FAST PET Workflow AI (Optional)

  • Creation of auto ranges and auto data export

CT Capability

  • SOMATOM® CT offers 64- or 128-slice CT configurations

Multiparametric PET Suite AI (Optional)

  • Adds the metabolic rate and distribution volume to the standard SUV image without the need for an invasive measurement

Exclusive bed design and wide bore

  • Zero differential deflection for accurate attenuation correction and TG-66 compliant along with a 78-cm bore to support bariatric imaging and easier positioning of radiation oncology devices

QualityGuard™ (Optional)

  • Uses intrinsic radioactive properties of Lutetium present on LSO detectors to automatically calibrate itself

iMAR (Optional)

  • Iterative algorithm for metal artifact reduction

Biograph Vision.X PET/CT with exclusive high-performance detector technology

Biograph Vision.X builds on the proven performance of Biograph Vision and delivers:


  • Time of flight (TOF) performance of 178 picoseconds (ps)industry’s fastest TOF4
  • Outstanding performance gain up to 20%,5 which can translate to faster scans as well as lower injected dose and radiotracer costs
  • In-field upgradeability

Cutting-edge technology

Biograph Vision.X leverages the in-house production of Siemens Healthineers across the entire imaging chain and demonstrates their commitment to delivering cutting-edge PET/CT technology to customers. Consider the power of each component along the imaging chain to deliver a better image.

Faster TOF

Biograph Vision.X with faster TOF reduces noise, which increases detectability of small lesions.


Biograph Vision.X is designed to be an in-field upgrade for installed Biograph Vision users, allowing youto extend the performance of your current system and offer next-level precision imaging.

Transcend digital with the Optiso UDR detector

Optiso UDR’s proprietary 3.2-mm LSO crystals move silicon photomultiplier (SiPM) technology beyond digital to a new level of precision to help you detect small lesions, devise accurate treatment strategies, and achieve optimal performance in a wide range of count rates.


Technical Details

Bore diameter 78 cm
Tunnel length 136 cm
Table capacity 227 kg (500 lb)
Generator power 80 kW (100 kW optional)
Rotation times 0.33, 0.305 , 0.28 5 s
Tube voltages 70, 80, 100, 120, 140 kV
Iterative reconstruction SAFIRE 5
Metal artifact reduction iMAR 5
Slices 64, 128
Axial field of view 26.3 cm
Crystal size 3.2 x 3.2 x 20 mm
SiPM coverage of crystal array 100%
Effective sensitivity 100 cps/kBq
Effective peak NEC rate

1,789 kcpskBq/cc

Time of flight performance 214 ps

Contact us today to learn more about how we can help you solve your most pressing challenges.

1 Biograph Vision and Biograph Vision.X are not commercially available in all countries. Their future availability cannot be guaranteed. Please contact your local Siemens Healthineers organization for further details.
2 Based on internal measurements available at time of publication. Data on file.
3 Compared to current state-of-the-art technologies. Data on file.
4 Fastest measured value on a single system. Based on competitive literature available at time of publication. Data on file.
5 Based on patient weight limit of 227 kg (500 lb).
