Biograph Vision Quadra
Jump to:
Bigger perspective. Better answers.
The power of a proven platform. The perspective of a large axial PET field of view. The Biograph Vision Quadra™ from Siemens Healthineers takes the potential of PET/CT further than ever before.
Dynamically see vertex to thighs in a single position and deepen the dimension of your investigations. Whether you’re exploring new research questions or identifying the best clinical approach, the answers are yours to find with the Biograph Vision Quadra.
/PET-CT/Biograph%20Vision%20Quadra/siemens-healthineers_mi_biograph_vision_quadra_built.jpeg)
Engineered for new research dimensions
With a 106 cm axial PET field of view, the Biograph Vision Quadra offers a whole-body (vertex to thighs) perspective so you can scan more in one position and dynamically follow tracer kinetics throughout the body. With best-in-class time-of-flight performance and PET effective sensitivity1 , you can see with outstanding clarity. From tumor perfusion over time to diverse physiological processes, pediatric imaging and more, the Biograph Vision Quadra exponentially expands your realm of investigation.
Reshape clinical outcomes
Get ready to deliver proven clinical outcomes at a greater scale.
The accuracy, performance and reproducibility of the Biograph Vision are the gold standard in PET/CT imaging. With the Biograph Vision Quadra, you achieve the same outstanding detail and definition you’ve come to expect: increased detectability of smaller lesions, reduced scan time, effective dose and faster evaluation of treatment impact 2 . But now, you also benefit from the higher effective sensitivity gained from a 106 cm axial PET field of view and the best time of flight1 , no matter your imaging application.
Designed for your everyday needs
Advance your vision
Be at the forefront of PET/CT. Leverage the power of a proven platform along with the perspective of a 106 cm axial PET field of view to lead the way in clinical and translational research. Pioneer therapies, develop breakthrough procedures, and facilitate novel diagnostics.
The Biograph Vision Quadra makes it possible while also adding streamlined information sharing to enhance your strategic collaborations and partnerships. Distinguish your institution and strengthen your ability to attract world‐class talent, whose ideas will become the advancements that define the next generation of healthcare.
Technical Details
Transcend digital with the Optiso UDR detector
Optiso UDR’s proprietary 3.2 mm LSO crystals move silicon photomultiplier (SiPM) technology beyond digital to a new level of precision to help you detect small lesions, devise accurate treatment strategies, and achieve optimal performance in a wide range of count rates.
** Measured value, based on phantom studies performed on a single system. Biograph Vision Quadra has a 803 cps/kBq effective sensitivity based on acceptance values. Data on file.
*** Measured value, based on phantom studies performed on a single system. Biograph Vision Quadra has ≤249 ps based on acceptance values. Data on file.
| Gantry | |
|---|---|
| Bore diameter | 78 cm |
| Tunnel length | 235 cm |
| Table capacity | 227 kg (500 lb) |
| CT | |
| Generator power | 100 kW |
| Rotation times | 1.0, 0.5, 0.33, 0.30, 0.28 s |
| Tube voltages | 70, 80, 100, 120, 140 kV |
| Iterative reconstruction | SAFIRE |
| Metal artifact reduction | iMAR* |
| Slices | 128 |
| PET | |
| Axial field of view | 106 cm |
| Crystal size | 3.2 x 3.2 x 20 mm |
| SiPM coverage of crystal array | 100% |
| Effective sensitivity | 1000 cps/kBq** |
| Time of flight performance | ≤228 ps*** |
Contact us today to learn more about how we can help you solve your most pressing challenges.
1 Measured value, based on phantom studies performed on a single system. Biograph Vision Quadra has ≤249ps time of flight performance based on acceptance values. Data on file.
2 Compared to Biograph mCT
